MER offer a complete solution to the common problem of impact damage at corners of pillars and walls of concrete structures. Our truly extensive range of corner guards allow designers the choice of function, style and finish to suit each environment. The most commonly selected areas are parking areas of the mall and residential buildings, garbage room interior pillars and so on where there will be chance of impact. Hence the usage of our rubber corner guard will eliminate the maintenance and will enhance the beauty of corner edges of the pillars
Available Standard Dimensions.
ITEM CODE |
WING SIZE (mm) a |
LENGTH (mm) b |
---|---|---|
CG7541 | 50X50 | 1000 |
CG7543 | 65X65 | 1000 |
CG7544 | 75X75 | 1000 |
CG7548 | 90X90 | 1000 |
CG7549 | 100X100 | 1000 |
CG7555 | 120X120 | 1000 |
Fixing: Screw & Plastic Fischer plugs
ITEM CODE |
WING SIZE (mm) a |
LENGTH (mm) b |
---|---|---|
CG7542 | 65X65 | 1000 |
CG7546 | 75X75 | 1000 |
CG7547 | 90X90 | 1000 |
CG7550 | 100X100 | 1000 |
CG7558 | 120X120 | 1000 |
CG7561 | 150X150 | 1000 |
ITEM CODE |
WING SIZE (mm) a |
LENGTH (mm) b |
---|---|---|
CG7540 | 50X50 | 1000 |
CG7545 | 75X75 | 1000 |
CG7552 | 100X100 | 1000 |
CG7559 | 120X120 | 1000 |
